Карта AWG Demux 48 длин волн 100GHz

Sintai
Артикул: PD48
112 399 руб.
Нашли цену дешевле?
- + шт Купить Добавлено Быстрый заказ
Зарегистрируйтесь, чтобы получить скидку!

The 48-channel AWG card is a pluggable passive forty-eight-channel 100GHz DWDM multiplexer or de-multiplexer (MUX & DEMUX) in a single 1U solution. It may be used in pairs to expand capacity in bidirectional transmission network.



Product Features



● High isolation, low insertion loss, high reliability and stability
● Support 48 DWDM Channels
● Easy installation without power supply or setting up the working environment
● No energy consumption and can meet environmental requirements

● No need to debug, no network management necessary, zero maintenance
● Support transparent transmission which is not related to the speed, format, content and applicability of the service
● OPC1600 passive chassis is used to load the card
● Adopt modular architecture design with long service life



Product Overview



The single fiber unidirectional passive pluggable 48-channel AWG card of Sintai Communication Co., Ltd has two function modules. Multiplexer board supports the multiplexing of 48-channel optical signals of WDM standard wavelength into one-core optical fiber for unidirectional transmission. De-multiplexer board divides the mixed optical signals transmitted by multiplexing board at the opposite end into the original multi-channel optical signals of WDM standard wavelength. By configuring 2 pairs of unidirectional wavelength division boards, it can expand the bidirectional transmission channel number to as many as 48 on two-core optical fibers.

Number of channels

48

Occupied slot number

2

Wavelength range

DWDM:C Band, 100 GHZ

Insertion loss

< 5.5 dB

Isolation ratio of adjacent channels

> 25 dB

Isolation ratio of non-adjacent channels

> 30 dB

Return loss

> 40 dB

Direction

> 45 dB

Interface type

All interfaces are LC type

Work temperature

-40~85℃

Storage temperature

-40~85℃



Производитель
Sintai
Задать вопрос
Подробно расскажем о наших товарах, видах и стоимости доставки, подготовим индивидуальное предложение для оптовых клиентов!

Карта AWG Demux 48 длин волн 100GHz

Карта одноволоконного пассивного демультиплексора DEMUX (100GHz, C-band 48*lambdas,C15..C62, LC)
